Wells, RCP-7200, Cold Food Well Unit, Drop-In, Refrigerated, Stainless Steel, Made In USA, 2 Pan

SKU #: RCP-7200
Description
Wells RCP-7200 Refrigerated Drop-In Cold Pans hold pre-chilled food products at cold, fresh, and safe serving temperatures and pans are recessed 3” to comply with NSF-7 Performance requirements. Unit is completely self-contained with individual thermostatic controls, use R-513A CFC free refrigerant system featuring sight glass, and include an 8 ft. cord and plug. One-piece top flange and coved-corner interiors constructed of stainless steel. Exterior body constructed of heavy gauge, corrosion resistant steel. Condensing unit mounted on corrosion resistant frame below the cold pan. Featuring wrapped coil construction on both sides and bottom, on/off switch, easy service valves, dryer/filter and receiver. Condensing unit may be easily removed for service. 1" drain, Two 12” x 20” pans.
?
Specifications
Number of Wells
1
Drain Outlet Size
1.0 Inch
Horsepower
1/4 hp
Amps
10 amps
Wattage
1200 watts
Voltage
120v
Phase
1PH
Capacity
2 pan
Width
25.88 Inch
Cutout Depth
25.88 Inch
Cutout Height
26.12 Inch
Height
26.13"
Depth
27.12"
Area (in)
32.75 Inch X 27.125 Inch X 26.13 Inch
Product Type
cold food well unit
Safety and Compliance
cULus, NSF
Design
drop-in, indoor, modular
Power Type
electric
Drain Type
Individual Drains
Features
insulated, Made in USA
Plug Type
NEMA 5-15
Refrigerant Type
R-134A
Shape
rectangular
Refrigeration
refrigerated
Compressor Style
self contained
Material
stainless steel
Temperature Control
thermostatic
Installation Type
top-mount
Drain Location
Underneath
